XHD Rock Bucket Grapple
72"
$5,364.00
Sale price
$5,364.00
Regular price
Skip to product information
XHD Rock Bucket Grapple
$5,364.00
Sale price
$5,364.00
Regular price
Details
Overview. The XHD Rock Bucket Grapple is the extreme-duty build for rock sorting and demolition work where thicker steel and more grappling force are required. Same proven sifting-bucket design as the standard model, but stepped up in frame, tines, and construction for higher-cycle and more punishing applications. Contact us for XHD-specific width and spec details.
Applications
- Heavy-cycle rock sorting and demolition cleanup
- Extreme-duty debris handling
- Large skid steer and loader applications
Core Specs
| Pins | 1 1/4" |
| Grappling Force | 15,000 lbs |
| Bottom Tines | 1/2" |
| Top Tines / Sides | 1/2" |
| Back | 1/4" |
| Cutting Edge | 3/4" x 6" |
| Main Frame | 4" Square Tubing 1/4" Sidewall |
| Step | Treaded step |
| Widths Stocked | 66", 72", 78", 84" |
Notable Features
- Independent tines allow dirt to fall through for cleaner loads
- Reinforced quick-attach; protected hoses and covered cylinders
- Treaded step for safe jobsite access
- Parker hoses, fittings, and couplers included
- XHD build for high-cycle, heavy-duty applications
