Standard Duty Root Grapple
60"
$3,547.00
Sale price
$3,547.00
Regular price
Skip to product information
Standard Duty Root Grapple
$3,547.00
Sale price
$3,547.00
Regular price
Details
Overview. This is the original Loflin root grapple design — not a copy — built for general land clearing and material handling on machines up to approximately 75 HP. It runs independent top tines, true job-site ready Parker plumbing, and fully protected hydraulics. Five standard widths are stocked, and custom sizing is available.
Applications
- Land clearing
- Brush and root removal
- General material handling
- Storm debris cleanup
Core Specs
| Overall Height | 33" |
| Overall Length | 41" |
| Main Frame | 4" Square Tubing 1/4" Sidewall |
| Opening Width | 34 1/4" |
| Grappling Force | 9,500 lbs |
| Cylinders | 2 x 10" |
| Tine Thickness | 1/2" |
| Tine Spacing | 8 1/2" – 9" |
| Pins | Oversized, greaseable 1 1/4" |
| Widths Stocked | 60", 66", 72", 78", 84" (custom available) |
| Recommended HP | Up to ~75 HP |
Notable Features
- Independent grapple tines allow dirt to fall through for cleaner loads
- Reinforced quick-attach; fully protected hoses and covered cylinders
- Fully greaseable hinge points; jobsite-ready Parker hoses, fittings, and couplers
- Slides over ground without digging in or catching utilities
- The original Loflin design — built here, not imitated
